ELECTRIC PARAMETERS
Input voltage: 100V~240V AC，50/60Hz
Power consumption:8W@ 220V(Max)
Current : 0.04A@220V(Max)
THE TYPES OF DIGITAL SIGNAL
DMX512：DMX512(1990), DMX512-A
RDM：V1.0 (E1.20-2010 ESTA Standard)
MAIN FUNCTIONS
1 channel input with 10-channel optoelectronic isolation signal outputs, or 2 channel inputs with their respective 5 channel optoelectronic isolation signal ouputs(selected by the switch)
Each signal output can be connected to 32 devices
Each input and output is with independent optoelectronic isolation technology with highest withstanding voltage 3KV
Each signal output is with independent LED indication for the status of the signal
Standard DMX 512 signal with 3-pin interface(optional 5-pin interface)
RDMfunction
AMBIENT TEMPERATURE
45℃ at maximum
INGRESS PROTECTION
IP20
WEIGHT
1.8Kg
INSTALLATION
1U Frame Type
OTHERS
Power in and out sockets
L shape fixing plates for both sides for front and back installation
