Input Voltages |
Control |
||
|
100-240V AC, 50/60Hz |
International DMX512, 3 pins and 5 pins interface |
||
|
Short mode 24 channels, standard mode 28 channels, extended mode 33 channels |
|||
|
Power Consumption |
self-test mode | ||
|
600W@100V |
|||
|
570W@220V |
Other Functions |
||
|
Adjustable pan & tilt speed |
|||
|
Light Source |
LCD display screen |
||
|
PHILIPS MSD Platinum Flex 300S |
Fixture and lamp usage time display |
||
|
(7,800K±300K, 6,000 hrs) |
Setup options by chargeable battery inside without power connection |
||
|
Modular structure for easy maintenance |
|||
|
Strobe |
DMX512 wireless receiver |
||
|
Double shutter blades, 0.3~25 F.P.S |
DMX512 wireless transmitter(optional) |
||
|
|
|||
|
Dimmer |
Physical |
||
|
0-100% linear adjustment |
Housing: high temperature engineering plastic, IP20 |
||
|
Ambient temperature: maximum 40℃ |
|||
|
Prism |
|||
|
Two prisms(standard: 8-facet and 16-facet prisms) |
Weight |
||
|
Optional: 3-facet prism and gradient prisms |
Net weight: 22.2Kg |
||
|
Bi-directional rotating at variable speeds |
|||
|
Packaging |
|||
|
Frost |
Standard: carton 640x510x530(mm) |
||
|
One frost filter |
Optional: flight case 860x550x750(mm) |
||
|
Independent Diffuser |
|||
|
One independent diffuser, optional even beam mode |
Accessories |
||
|
G clamp, 2 pcs |
|||
|
Focus |
5 pins XLR connector, 1 set |
||
|
DMX linear focus |
Safety cord, 1 pc |
||
|
Power cord, 1 pc |
|||
|
Zoom |
Optional: Ω clamp, 2 pcs | ||
|
DMX linear zoom |
|||
|
Head Movement |
|||
|
Pan 540°, tilt 270° with auto position correction |
|||
|
Light Angle |
|||
|
Beam mode: 2.3°~10° |
|||
|
Spot mode: 2.3°~40° |
|||
|
Wash mode: 5°~50° |
|||
| CMY | |||
|
CMY linear color mixing with macros |
|||
| Color Wheel | |||
|
1 Color wheel: 13 dichroic color filters(with CTO) plus open |
|||
|
Rainbow effect with bi-directional and variable speeds |
|||
|
Stepping/linear color changing |
|||
| Fixed Gobo | |||
|
1 Fixed gobo wheel: 10 gobos+open+ animation effect |
|||
|
Bi-directionally rotatable, and shakable effect at variable speeds |
|||
| 2 channels to control gobos and shift between animation effects | |||
| Rotating Gobo | |||
|
1 Rotating gobo wheel: 9 interchangeable gobos plus open |
|||
|
Bi-directionally rotatable, and shakable at variable speeds |
|||
