| ELECTRICAL PARAMETER Input Voltages : 100V~240V AC，50/60Hz Rated Power : 650W @ 220V Power Factor：PF >0.9 LAMP SPECIFICATIONS: Lamp ：PR480L ColorTemperature ：6900K ManufacturersRatedLampLife ：1500hours PRISM: 2Pcs,(STD 8-facet and 16 facet Prisms) Bi-directional rotation with variable speeds(options: 3-facet/ 16-facet liner prism or gradient prism) INDEPENDENTDIFFUSER: 1Pcs ofindependent diffuser Optional even beammode FROST: 1Pc frostfilter FOCUS: DMX linearFocus ZOOM: DMX linearZoom DIMMER/STROBE: 0-100% Linearly adjustable/Double shutter blades, 0.3~25 F.P.S HEADMOVEMENT: Pan 540º,Tilt 270º with auto position correction |
BEAMANGLE: Beam Mode: 2.3°-- 10°, LinearAdjustment SpotMode: 5°-- 40°LinearAdjustment WashMode: 5°-- 50°LinearAdjustment CONTROL: DMX512, 5 pin interfaces 24channelsin shortmode, 28channelsin standardmode , 33channelsin extendedmode Self-testmode OTHER FUNCTIONS: AdjustablePan&Tiltspeeds Lamp’s and fixture’s hours displayed Modular Structure for easymaintenance DMX512wirlessreciever OptionalDMX512WirelessTransmitter22 HOUSING: High temperatureABS,IP20 NETWEIGHT: 22.2Kg WEIGHT: NetWeight: 22.2Kg GrossWeight: 79Kg in flight case(2pcs/case) and accessories NetWeight: 26.5Kg in carton(1pc/ctn) and accessories OPERATIONTEMPERATURE: Maximumambient temperature: 40°C |
| 【Version：20230921】 |
1 Color wheel: 13colors(plus 1CTO)+ Open, rainbow effect with bi-directional and variable speeds, Stepping/linear color changing
CMY linear color mixing with macros
1 Fixed gobo wheel: 10 gobos +open+ animation effect
Bi-directionally rotatable, and shakable at variable speeds, 2channels to shift between gobos and animation effects.
1 Rotating gobo wheel:9Interchangeable Gobos +Open
