| Light Source | Channels | ||
| OSRAM 60x3W(17R＋17G＋17B＋6W+3A), 50000 hrs | Short mode 8 channels, standard mode 12 channels and extended mode 16 channels | ||
| Input Voltages | Housing | ||
| 100V~240V AC, 50/60Hz | High intensity cast aluminum alloy | ||
| IP20 | |||
| Power Consumption | |||
| 200W@220V | Net Weight | ||
| 3.9kg | |||
| Strobe | |||
| Electronic strobe, 0-25 F.P.S | |||
| Dimmer | |||
| 0-100% linearly adjustable | |||
| Effect | |||
| Rainbow and animation effects | |||
| Light Angle | |||
| Beam angle(1/2 Maximum) θ1/2: 15° | |||
| Field angle(1/10 Maximum) θ1/10: 28° | |||
| Lens angle: 15° (optional 8°, 25 °, 45°) | |||
| Control | |||
| DMX512, 5 pins(optional 3 pins) intereface | |||
| Color System | |||
| R/G/B/W/A and color mixing , with macro | |||
| Color Temperature | |||
| Linear color temperature correction from 3,200K to 10,000K | |||
