Input Voltages |
Control |
||
|
100-240V AC, 50/60Hz |
International standard DMX512 signal control protocol |
||
|
Standard mode 6 channels and extended mode 11 channels |
|||
|
Power Consumption |
Master/Slave synchronized Mode |
||
|
180W@220V |
3 operation modes(DMX mode, user memory, preset memory) |
||
|
|
|||
|
Light Source |
Physical |
||
| 54pcsX3W RGBW light source（162W） , 50000 hrs |
Housing: high intensity cast aluminum alloy, IP67 |
||
|
Ambient working temperature: -20°C~40°C |
|||
|
Strobe |
|||
|
Electronic strobe, 0.5-33 F.P.S |
Weight |
||
|
Net weight: 10kg |
|||
|
Dimmer |
|||
|
0-100% linear adjustment |
Packaging |
||
|
Standard: carton 700x690x480(mm), 4 in 1 |
|||
|
Light Angle |
Optional: flight case 875x590x512(mm), 4 in 1 |
||
|
Beam angle(1/2 peak) θ1/2: 8° (optional 7°, 10°, 20°, 40°) |
|||
|
Accessories |
|||
|
Other Functions |
Clamp, 1 pc |
||
|
LCD screen and its brightness adjustable |
Signal adapter cord, 2 pcs |
||
|
DMX channel mode and setting display |
Power cord, 1 pc |
||
|
LCD display and menus invertible |
Safety cord, 1 pc |
||
| Backlight of LCD display automatically turns off after some delay
|
Optional: transparent cover+seal+screws x6, 1set; |
||
| Control mode and other information can be transmitted via synchronization | barndoor assembly+frost board, 1 set; top hat, 1 set | ||
| 【Version：20240426】 | |||
| Color System | |||
|
R/G/B/W, optional(R/G/B/Amber, R/G/B/Lime) |
|||
