Input Voltages | Control | ||
100-240V AC, 50/60Hz | International DMX512, 3 pins interface | ||
Standard mode 2 channels | |||
Power Consumption | Master-slave mode, test mode | ||
180W@220V | DMX control mode, preset memory and user memory | ||
Light Source | Physical | ||
PHILIPS 12x15W LEDs white, 50,000 hrs | Housing: high intensity cast aluminum alloy, IP67 | ||
Ambient working temperature: -20°C~40°C | |||
Strobe | |||
Electronic strobe, 0.5-33 F.P.S | Weight | ||
Net weight: 10kg | |||
Dimmer | |||
0-100% linear adjustment | Packaging | ||
Standard: carton 700x690x480(mm),4 in 1 | |||
Light Angle | Optional: flight case | ||
Beam angle(1/2 peak) θ1/2: 14°(optional 10°, 20° and 40°) | |||
Accessories | |||
Other Functions | C clamp, 1 pc | ||
LED board temperature and fixture usage time can be checked via menu | Signal adapter cord, 2 pcs | ||
DMX channel mode and settings displayed | Power cord, 1 pc | ||
LED and inverted display | Safety cord, 1 pc | ||
Display backlight automatically shut off after delay | Optional: N/A | ||
Transmitted under synchronization | |||
