Input Voltages

Control

100-240V AC, 50/60Hz

International DMX512, 3 pins interface

Standard mode 6 channels and extended mode 11 channels

Power Consumption

Master-slave mode, test mode

180W@220V

DMX control mode, preset memory and user memory

Light Source

Physical

PHILIPS 12x15W LEDs(RGBA 4 in 1), 50,000 hrs

Housing: high intensity cast aluminum alloy, IP67

Ambient working temperature: -20°C~40°C

Strobe

Electronic strobe, 0.5-33 F.P.S

Weight

Net weight: 10kg

Dimmer

0-100% linear adjustment

Packaging

Standard: carton 700x690x480(mm), 4 in 1

Light Angle

Optional: flight case 875x590x512(mm), 4 in 1

Beam angle(1/2 peak) θ1/2: 14°(optional 10°, 20° and 40°)

Accessories

Other Functions

C clamp, 1 pc

LED board temperature and fixture usage time can be checked via menu

Signal adapter cord, 2 pcs

DMX channel mode and settings displayed

Power cord, 1 pc

LED and inverted display

Safety cord, 1 pc

Display backlight automatically shut off after delay

Transmitted under synchronization
