Input Voltages | Control | ||
100V~240V AC,50/60Hz | International DMX512, 3 pins interface | ||
Short mode 7 channels, standard mode 10 channels | |||
Power Consumption | Master-slave mode, stand-alone mode | ||
320W@230V | |||
Physical | |||
Light Source | Housing: high-intensity die-casting aluminum, IP65 | ||
PHILIPS 24x15W LEDs(RGBW 4 in 1), 50,000 hrs | Ambient working temperature: -20°C~45°C | ||
Strobe | Weight | ||
Electronic strobe, 1-25 F.P.S | Net weight: 20kg | ||
Dimmer | Packaging | ||
0-100% linear adjustment | Standard: carton 550x480x470(mm) | ||
Optional: flight case | |||
Light Angle | |||
Beam angle (1/2 peak) θ1/2: 16°(optional: 22° and 30°) | Accessories | ||
C clamp, 1 pc | |||
Other Functions | Signal adapter cord, 2 pcs | ||
LCD panel | Power cord, 1 pc | ||
Over temperature protection | Safety cord, 1 pc | ||
Fast and convenient software upgrade via DMX512 interface | Optional: transparent cover+ seal+ screws x6, 1set | ||
Built in NTC temperature detecting function, If LED lamp is over heat | |||
| its power will be decreased intelligently | |||
| Color System | |||
RGBW and color mixing | |||
