Input Voltages |
Control |
||
|
100V~240V AC,50/60Hz |
International DMX512, 3 pins interface |
||
|
Short mode 7 channels, standard mode 10 channels |
|||
|
Power Consumption |
Master-slave mode, stand-alone mode |
||
|
320W@230V |
|||
|
Physical |
|||
|
Light Source |
Housing: high-intensity die-casting aluminum, IP65 |
||
|
PHILIPS 24x15W LEDs(RGBW 4 in 1), 50,000 hrs |
Ambient working temperature: -20°C~45°C |
||
|
|
|||
|
Strobe |
Weight | ||
|
Electronic strobe, 1-25 F.P.S |
Net weight: 20kg |
||
|
|
|||
|
Dimmer |
Packaging |
||
|
0-100% linear adjustment |
Standard: carton 550x480x470(mm) |
||
|
Optional: flight case |
|||
|
Light Angle |
|||
|
Beam angle (1/2 peak) θ1/2: 16°(optional: 22° and 30°) |
Accessories |
||
|
C clamp, 1 pc |
|||
|
Other Functions |
Signal adapter cord, 2 pcs |
||
|
LCD panel |
Power cord, 1 pc |
||
|
Over temperature protection |
Safety cord, 1 pc |
||
|
Fast and convenient software upgrade via DMX512 interface |
Optional: transparent cover+ seal+ screws x6, 1set | ||
|
Built in NTC temperature detecting function, If LED lamp is over heat |
|||
| its power will be decreased intelligently | |||
| Color System | |||
|
RGBW and color mixing |
|||
