Input Voltages |
Control | ||
|
100-240V AC, 50/60Hz |
International standard DMX512 signal control protocol DMX512 3 pin and 5 pin interfaces | ||
|
5 Control modes: basic, standard, extended and HIS/HSIC modes |
|||
|
Power Consumption |
Master/Slave synchronized Mode Standard alone mode, preset mode, self test mode and single scene mode |
||
|
220W@220V |
3 operation modes(DMX mode, user memory, preset memory) | ||
|
|
|||
|
Light Source |
Physical |
||
|
OSRAM 14x15W LEDs(RGBW 4 in 1), 50,000 hrs |
Housing: high intensity cast aluminum alloy, IP67 |
||
| Maximum ambient temperature: 40 ℃ | |||
|
Strobe |
|||
|
Electronic strobe, 0-25 F.P.S |
Weight |
||
|
Net weight: 10kg |
|||
|
Dimmer |
|||
|
0-100% linear adjustment |
Packaging |
||
|
Standard: carton 727x727×481(mm), 4 in 1 |
|||
|
Light Angle |
Optional: flight case 875x590x512(mm), 4 in 1 |
||
|
Beam angle(1/2 peak) θ1/2: 14°~42° |
|||
|
Field angle(1/10 peak): 23°~68° |
Accessories |
||
|
G clamp, 1 pc |
|||
|
Other Functions |
Power cord, 1 pc |
||
|
LCD screen and its brightness adjustable |
XLR cable, 2 pcs |
||
| Wireless control function(Optional) | Safety cord, 1 pc | ||
| DMX 512 port for firmware upgrade, a convenient and quick way for firmware upgrade via DMX cable | User manua, 1 set | ||
| Over temperature protection | Transparent Cover+ seal+ screws ×6，1 set（optional） | ||
| Fixture time, DMX512 channel value and software version will be displayed | Barn Door + Frost panel(Optional)，1 set | ||
| Display can be inverted | |||
【Version：20220219】 |
|||
| Colors | |||
| R/G/B/W, Macros, unlimited color mixings | |||
