Input Voltages |
Light Angle | ||
|
100-240V AC, 50/60Hz |
6°~56° | ||
|
Power Consumption |
Control |
||
|
1100W@220V, 1140W@100V |
International DMX512, 5 pins interface |
||
|
RDM control protocol |
|||
|
Light Source |
Short mode 26 channels, standard mode 31 channels, extended mode 46 channels |
||
|
800W LED white(7,000K), 20,000 hrs |
Master-slave mode, stand-alone mode, test mode |
||
|
|
|||
|
Strobe |
Other Functions |
||
|
Electronic strobe, 0.3-25 F.P.S |
Lamp and total hours displayed |
||
|
Over temperature protection |
|||
|
Dimmer |
Fast and convenient software upgrade via DMX512 interface |
||
|
0-100% linear adjustment |
Input signal isolation |
||
|
Modular structure for easy maintenance |
|||
|
CTO |
DMX512 wireless receiver |
||
|
0-100% linear CTO system |
DMX512 wireless transmitter(optional) |
||
|
|
|||
|
Prism |
Physical |
||
|
One 4-facet prism, bi-directionalat variable speeds, index function |
Housing: high-intensity die-casting aluminum, IP66 |
||
|
Ambient working temperature: 45°C |
|||
|
Effect |
|||
|
Dual effect wheel, independent bi-directional rotation at variable speeds |
Weight |
||
|
Shaking effect at variable speeds |
Net weight: 42kg |
||
|
Frost |
Packaging |
||
|
One linear frost filter |
Standard: carton , Optional: flight case |
||
|
|
|||
|
Focus |
Accessories | ||
|
DMX linear focus |
Safety cord, 1 pcs |
||
| Color Wheel | |||
|
1 Color wheel: 6 dichroic color filters plus open |
|||
|
Half color effect, rainbow effect with bi-directional and variable speeds |
|||
| Stepping/linear color changing | |||
| Fixed Gobo | |||
|
1 Fixed gobo wheel: 7 replaceable gobos plus open, glass and metal gobos can be fixed |
|||
|
Bi-drectionally rotating, index, shaking at variable speed |
|||
| Rotating Gobo | |||
|
1 Rotating gobo wheel: 6 replaceable gobos plus open, glass and metal gobos can be fixed |
|||
|
Bi-drectionally rotating, index, shaking at variable speed |
|||
| Framing | |||
|
4 Framing blades, rotates between 0° and 90° and produces graphics of different shapes and sizes, curtain effect |
|||
