Input Voltages | Control | ||
208V~240V AC，50/60Hz | DMX512, 5 pin interfaces | ||
| RDM and Art-Net controls with options for RJ45 interfaces | |||
Input Power | wireless DMX control and SCAN protocol | ||
1800W@220V | 28channels in short mode | ||
Power factor: PF>0.9 | 34channels in standard mode and 39channels in extended mode | ||
Self-test mode | |||
Light Source (With 1400W Ballast And Igniter) | |||
OSRAM lok-it 1400/PS (6000K,CRI >95,single ended ,750hrs) | Other Function | ||
Adjustable Pan & Tilt speed | |||
Cto | Lamp and Total hours displayed | ||
0-100% linear CTO | Color touch screen ,English and Chinese menus | ||
Display invertible and Auto fan speed control | |||
Prism | Energy saving ballast | ||
1pc of 3 facet prism | Built-in sensor diagnostic system | ||
Bi-directional rotation with variable speeds and indexing function | Input signal isolation | ||
Modular Structure for easy maintenance | |||
Frost | DMX channel monitoring | ||
1pc frost filter, linear frost effect | Magnet sensor positioning with signal feedback | ||
absolute position memeroy, Auto-positioning after DMX signal disruption or power off | |||
Effect Wheel | Firmware upgrade via DMX | ||
1pc, replaceable, bi-directional rotation with variable speeds | |||
Housing | |||
Focus | High temperature ABS, IP20 | ||
DMX linear Focusing | |||
Net Weight | |||
Dimmer | 45Kg | ||
0-100% Linear adjustment | |||
two options for dimmer curves: linear dimmer curve and square law curve | Operation Temperature | ||
As for square law curve | Ambient temperature at maximum：40°C | ||
it has wider range and is more smooth in black environments | |||
Accessories | |||
Iris | Clamps 2 Pcs | ||
5-100% linear adjustment with macros | XLR Connector 1 Set Male and female | ||
Safety cord 2 Pc | |||
Strobe | User manual 1 Pc | ||
Double shutter blades, 0.3~25 F.P.S | |||
Noise | |||
Head Movement | Less than 45 dBA | ||
Pan 540º, Tilt 270º with auto position correction | |||
Beam Angle | |||
linear zoom 6°～ 55°with 16 bit function | |||
| CMY | |||
CMY linear mixing system with macros | |||
| Color Wheel | |||
1 Color wheel: 7 colors + open | |||
Half color effect, rainbow effect with bi-directional and variable speeds | |||
Stepping/linear color changing | |||
| Fixed Gobo | |||
1 fixed gob wheel: 7 replaceable gobos+ Opem | |||
Gobo Shake Effect with variable speeds, bi-directional scrolling with variable speeds | |||
| Rotating Gobo | |||
2 Rotating Gobo Wheel: 6 replaceable gobos+ Open, Glass or Metal Gobo | |||
Bi-directional Rotation with variable speeds | |||
| With Indexing Function | |||
Gobo Shake Effect with Variable Speeds | |||
Bi-directional Scrolling with Variable Speeds | |||
