Input Voltage

Control

100V-240V AC，50/60Hz

International standard DMX512 signal , 5 pin interface

RDM control protocol

Input Power

ArtNet protocol

1140W @ 100V AC

27channels in short mode, 31channels in standard mode,38channel in extended mode

1080W @ 220V AC

Master/Slave mode

Power factor: PF>0.9

Stand-alone mode

Self test mode

Light Source

Lamp 800W (8000K,20000hrs)

Other Functions

Adjustable Pan & Tilt speeds

Ra ≥90, R9≥90 (Optional)

Pan and Tilt swappable and invertible

Fixture and lamp hours’ display

Color screen, Chinese-English menus, brightness and contrast adjustable

Cto

Diagnostic system with sensors

Linear CTO system(0-100%)

Software version display

Protection and insulation of input signals

Prism

Modular construction for easy maintenance

1pc 4 facet prism, bi-directional rotation with varied speeds and indexing function

ArtNet interface

DMX512 wireless receiver

Frost

DMX512 wireless transmitter (optional)

Linear frost (0-100%)

Housing

Effect Wheel

High tensile cast aluminum and high temperature resistant ABS, IP66

1 exchangeable graphic effect wheel, bi-directional rotation with varied speeds

Ambient Temperature

Focus

-20℃ ~ 45℃

0-100% linearly adjustable by DMX

Note: if the ambient temperature is below -20°C

please preheat the lamp more than 30 minutes and reset it again

Dimmer

Linear dimmer 0-100%

3 dimmer speeds

55Kg

4 dimmer gamma curves

Dimmer frequency(1.2K~2.5K) good for high speed 4K video camera

Accessories

G clamp  2  Pcs

Iris

XLR connector  1  Set   Male and female

Linear iris 5-100% with macros

Safety cord   2  Pcs

User manual 1  Pc

Strobe

Ω clamp  2  Pcs  Optional

Double shutter blades, 0.3~25 F.P.S

Head Movement

Pan 540º, Tilt 270º with auto position correction

Beam Angle

Linear zoom 6°～  56°with 16 bit precision
