Input Voltages | Other Functions | ||
100V~240V AC，50/60Hz | LED lamp board temperature and fixture time available in the menus | ||
DMX channel mode and settings displayed | |||
Input Power | LCD and inverted display | ||
350W@220V | Display backlight automatically shut off after delay | ||
Parameters like operation mode and etc. transmitted under synchronization | |||
Environment brightness and timer controllable | |||
Light Source | Housing | ||
27pcs of LED lamp RGBW (10W, 50000hours) | High tensile cast Aluminum alloy , IP65 | ||
| Colors | Net Weight | ||
| RGBW linear color mixing with macros | 18Kg | ||
| Linear color temperature adjustment | |||
| Dimmer | Operation Temperature | ||
| Linear dimmer (0-100%) | -20°C～40°C | ||
Strobe | Accessories | ||
| Electronic Strobe 1-33.FP.S. | Barn Door 1 Set Optional | ||
G clamps 2 Pcs | |||
| Beam Angle | XLR Loop Cable 1 Pc Male,0.3m long | ||
Field Angle(1/10 peak): θ: 76° | XLR Loop Cable 1 Pc Female,0.3m long | ||
| Beam Angle(1/2peak) θ1/2 ：37° | Safety cord 1 Pc | ||
| Standard lens: 45° Optional Lens 11°，15°, 25° | User manual 1 Pc | ||
Transparent Water proof panel + seal+ screws X8 1 Set | |||
Control | Optional for harsh environment installation like underwater, dusty area | ||
| DMX512, 3 pin and 5 pin interfaces | |||
6channels in standard mode and 11channels in extended mode | |||
Wireless DMX Signal | |||
Master/Slave Mode | |||
3 Operation Modes(DMX Mode, Preset Memory, user Memory) | |||
Test Mode | |||
