Input Voltages |
Other Functions |
||
|
100V~240V AC，50/60Hz |
Color touch screen and its brightness adjustable |
||
|
DMX 512 port for firmware upgrade, a convenient and quick way for firmware upgrade via DMX cable |
|||
|
Input Power |
Over temperature protection |
||
|
300W @ 230V |
Built-in NTC temperature monitoring function, if LED lamp is over temperature, |
||
|
its output will be decreased intelligently Fixture time, DMX512 channel value |
|||
|
and software version will be displayed a Display can be inverted |
|||
|
|
|||
|
Light Source |
Housing | ||
|
TX5266 250W , White LED(6500K, 50000hours) |
High tensile cast Aluminum , IP65 | ||
|
|
|||
| Colors |
Net Weight |
||
|
1pc color wheel(7colors +Open, custom colors) |
Net weight 17.8Kg |
||
| continual rotation, magnetic sensor for positioning |
Gross weight of 20Kg in cardboard |
||
|
|
|||
| Function |
Operation Temperature |
||
|
2 water wave effect wheel, independently rotating,bi-directional and continual rotation |
Maximum ambient temperature 45 ℃ |
||
| 1 waterproof cooling fan |
|
||
|
Motorized focus and zoom |
|
||
|
|
|||
|
Dimmer |
Accessories | ||
|
Linear Dimmer from 0-100% |
Safety cord 1 pc | ||
|
User manual 1 pc |
|||
|
Strobe |
|||
| Electronic Strobe 0-25FP.S. With preset strobe pulse effect |
|
||
|
|
|||
|
Beam Angle |
|
||
| Beam angle(Field angle) 25°～ 50° linear focus |
|
||
|
|
|
||
| Control |
|
||
|
DMX512 signal control protocol with DMX512 5pin(Optional 3 pin )interfaces |
|
||
|
Master/Slave synchronized Mode |
|
||
|
Stand alone mode, preset mode and static scene mode |
|
||
|
3 operation mode(DMX mode, user memory mode and preset memory mode) |
|
||
|
|
|
||
|
|
|
||
|
|
|
||
|
|
|||
|
|
|||
|
|
|||
|
|
|
