Input Voltages |
Control |
||
|
100V~240V AC，50/60Hz |
DMX512 signal control protocol DMX512 5pin(Optional 3 pin )interfaces |
||
|
18channels in short mode,23channels in standard mode and 26 channels in extended mode |
|||
|
Input Power |
Master/Slave synchronized Mode |
||
|
400W @ 230V |
Stand alone mode, preset mode, self test mode and static scene mode |
||
| Power factor: PF>0.9 |
|
||
|
|
|
||
|
Light Source |
Other Functions | ||
|
300W , White LED (20000hours,8000K) |
Color touch screen and its brightness adjustable | ||
|
DMX 512 port for firmware upgrade, a convenient and quick way for firmware upgrade via DMX cable |
|||
| Strobe |
Over temperature protection |
||
|
Electronic Strobe 0-25FP.S. With preset strobe pulse effect |
Fixture time, DMX512 channel value and software version will be displayed a Display can be inverted |
||
|
Quick replacement of gobos |
|||
|
|
|||
| Dimmer |
Housing |
||
|
Linear Dimmer from 0-100% |
Cast Aluminum , high temperature resistant/anti-UV ABS,IP65 |
||
|
|
|||
| Colors |
Net Weight |
||
|
CMY linear color mixing with macros |
21.4Kg | ||
| 1pc color wheel(6colors+CTO+Open), |
Gross weight of 25Kg in cardboard) |
||
| Half color, bi-directional rainbow effect with variable speeds |
|
||
|
Stepping /linear color selection |
|||
|
|
|||
| Prism |
Operation Temperature |
||
|
1pc 4-facet circular prism |
Maximum ambient temperature 45 ℃ |
||
|
|
|||
| Effect Wheel |
Accessories |
||
|
1 fire effect wheel(bi-directional rotation with variable speeds) |
Safety cord 1 Pc |
||
| Fire gobo exchangeable |
User manual 1 Pc |
||
|
|
|
||
|
Rotating Gobo Wheel |
|
||
|
1pc of rotating gobo wheel:6 gobos +open |
|
||
|
Shake with variable speeds, bi-directional scrolling with variable speeds |
|
||
|
Gobo exchangeable |
|
||
|
|
|
||
|
Focus |
|||
|
DMX linear focus |
|||
|
|
|||
|
Zoom |
|||
|
DMX linear zoom |
|||
|
|
|||
|
Beam Angle |
|||
|
Beam angle (1/2θpeak): linear focus 7°～ 45° |
|||
|
|
|||
|
Frost |
|||
|
1frost filter |
|||
|
|
|||
|
|
|
