Input Voltages | Other function | ||
100V~240V AC，50/60Hz | LCD screen | ||
DMX 512 port for firmware upgrade, a convenient and quick way for firmware upgrade via DMX cable | |||
Input Power | Over temperature protection | ||
180W@220V | Built-in NTC thermal monitoring. LED’s output power will be automatically decreased if over-temperature occurs Fixture time and software version will be displayed | ||
| Power factor: PF>0.9 | Display can be inverted | ||
Light Source | Housing | ||
150W White LED,1pc（7500K），20000hrs | High tensile cast aluminum , IP66 | ||
Functions | Net Weight | ||
1color wheel, 5colors+open | 9Kg | ||
| 1 rotating gobo wheel, 5gobos+open, custom gobo available | |||
1 3-facet circular prism, bi-direction rotation | |||
| Focus | Packaging | ||
0-100% linear focus | Standard: carton 700x690x480(mm) | ||
| Zoom | Operation Temperature | ||
Fixed zoom 55°,optional 30° | Highest ambient temperature 40℃ | ||
| Dimmer | Accessories | ||
0-100% linear adjustment | Safety cord 1 Pc | ||
User manual 0 Pc QR code | |||
| Strobe | |||
Electronic Strobe 0-25FP.S. with preset strobe pulse effect | |||
| Beam angle | |||
55°with motorized focus | |||
| Control | |||
International standard DMX512 signal control protocol | |||
| DMX512 3 pin and 5 pin interfaces | |||
Master/Slave synchronized Mode | |||
Stand alone mode, preset mode, self test mode and static scene mode | |||
3 operation modes(DMX mode, user memory, presetmemory) | |||
