Input Voltages |
Tilt |
||
|
100V~240V AC,50/60Hz |
270° |
||
|
|
|
||
|
Input Power |
Beam Angle |
||
|
1040W@220V AC 1090W @ 100V AC |
linear zoom 6°~ 56°(open)with 16 bit function | ||
| Power factor: PF>0.9 |
|
||
|
|
|
||
|
Light Source |
Control | ||
|
800W (8000K, 20000hrs) |
DMX512, 5 pin interfaces | ||
|
RDM control protocol |
|||
|
Colors |
22channels in short mode,26channels in standard mode and 33channels in extended mode |
||
|
CMY linear mixing system with macros |
Master/Slave synchronized mode | ||
| 1 color wheel: 6exchangeable colors+ Open |
Stand-alone mode |
||
|
Half color effect, rainbow effect with bi-directional and variable speeds |
|
||
|
Stepping/linear color changing |
|
||
|
|
|||
| CTO |
Other Function |
||
|
0-100% linear CTO |
Total hours displayable |
||
|
English and Chinese menus |
|||
| Gobo |
Built-in sensor diagnostic system |
||
|
2Rotating Gobo Wheels: 6 replaceable gobos+ Open, Glass or Metal Gobo |
Software versions displayable | ||
|
Bi-directional Rotation with variable speeds |
Input signal isolation | ||
|
With Indexing Function |
Modular Structure for easy maintenance | ||
|
Gobo Shake Effect with Variable Speeds |
|||
|
Bi-directional Scrolling with Variable Speeds |
|||
|
|
|||
| Prism |
Housing |
||
|
1pc of 4 facet prism , Bi-directional rotation with variable speeds and indexing function |
High temperature ABS+ High tensile cast aluminum , IP66 | ||
|
|
|
||
| Frost |
Net Weight |
||
| 1pc frost filter, linear frost effect( 0%-100%) |
40Kg |
||
|
|
|||
| Effect Wheel |
Operation Temperature |
||
|
1pc graphic effect wheel , replaceable, bi-directional rotation with variable speeds |
-20℃~ 45℃ |
||
|
Note: If the ambient temperature is below -20 ° C, |
|||
| Focus |
reset a projector before pre-heating it for more than 30 minutes |
||
| DMX linear Focusing |
|
||
|
|
|||
| Dimmer |
Accessories |
||
|
0-100% Linear adjustment |
User manual 1 Pc |
||
|
|
Safety cord 1 Pc |
||
|
Iris |
|||
|
5-100% linear iris with macros |
|||
|
|
|||
|
Strobe |
|||
|
Double shutter blades, 0.3~25 F.P.S |
|||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
|
|
|||
|
|
|
