Input Voltage |
Beam Angle |
||
|
100V~240V AC，50/60Hz |
Beam angle：0.8° |
||
|
|
|||
|
Power Consumption |
Control |
||
|
390W @ 220V |
International standard DMX 512 signal,5-pin XLR connectors |
||
|
Short Mode 15 channels，standard Mode 17channels,extended mode 18channels |
|||
|
Light Sources |
Self test mode |
||
|
260W laser module(9000K,12000hrs) |
|
||
|
Other Functions |
|||
|
Prism/Frost |
Pan and Tilt speeds adjustable |
||
|
3 prism wheels: (a 8-facet circular prism+ a 4-facet linear prism ) |
Lamp hours and fixture hours displayed |
||
| 1 wheel (a 16-facet circular prism + a frost filter) |
Modular construction easy for maintenance |
||
|
Other prism options available |
Wireless receiver |
||
|
Wireless transmitter (Optional) |
|||
|
Focus |
ArtNet and sACN (Optional) |
||
|
DMX linear focus |
|
||
|
|
|||
|
Strobe/Dimmer |
Housing and ingress protection |
||
|
Double flag strobe，0.3-25 F.P.S. / linear dimmer |
Cast aluminum and high temperature and UV resistant ABS with IP66 |
||
|
|
|||
|
Movements |
Net Weight |
||
|
Pan (0°-540°)，Tilt( 0°-270°) with auto positioning correction function |
37.6Kgs |
||
|
|
|||
|
Ambient Temperature |
Accessories |
||
|
-20 °C ~ 45 °C |
Safety cord 1 Pc |
||
|
Note：If a fixture runs with the ambient temperature below 0 Celsius |
User manual 1 Pc |
||
|
it should be heated for some time(less than 20 minutes based on actual conditions) |
|
||
|
before turning on the laser module |
【Version: 20240424】 | ||
|
|
|||
|
|
| Color Wheel | |||
|
1 color wheel: 19 colors + open |
|||
|
Macros and bi-directional rainbow effects with variable speeds |
|||
|
|
|||
| Fixed Gobo | |||
|
1 fixed gobo wheel：30 gobos+open |
|||
|
Shakable at variable speeds and bi-directional rotation at variable speeds |
|||
