Input Voltage | Beam Angle | ||
100V~240V AC，50/60Hz | Beam angle：0.8° | ||
Power Consumption | Control | ||
420W @ 220V | International standard DMX 512 signal,5-pin XLR connectors | ||
Short Mode 21 channels，standard Mode 25 channels,extended mode 28 channels | |||
Light Sources | Self test mode | ||
260W laser module (9000K,12000hrs) | Other Functions | ||
Pan and Tilt speeds adjustable | |||
Prism/Frost | Lamp hours and fixture hours displayed | ||
2 prism wheels: 1 wheel (an 8-facet circular prism+ a 4-facet linear prism ) | Modular construction easy for maintenance | ||
| 1 wheel (a 16-facet circular prism + a frost filter) | Wireless receiver | ||
| prisms overlapped. Other prism options available | Optional wireless transmitter | ||
Optional Art-Net function | |||
Focus | |||
DMX linear focus | Housing | ||
Cast aluminum and high temperature and UV resistant ABS with IP66 | |||
Strobe/Dimmer | |||
Double flag strobe，0.3-25 F.P.S. / linear dimmer | Net Weight | ||
39Kgs | |||
Movements | |||
Pan (0°-540°)，Tilt( 0°-270°) with auto positioning correction function | Accessories | ||
Safety cord 1 Pc | |||
Ambient Temperature | User manual 1 Pc | ||
45°C at maximum for ambient temperature | |||
| Color Wheel | |||
1 color wheel：19 colors+open | |||
Macros and bi-directional rainbow effects with variable speeds | |||
| a linear CYM color mixing system | |||
| Fixed Gobo | |||
1 fixed gobo wheel：30 gobos | |||
Shakable at variable speeds and bi-directional rotation at variable speeds | |||
1Rotating gobo wheel: 12 gobos+ Open | |||
Shaking and bi-directional wheel scrolling at variable speeds | |||
