Input Voltage | Beam Angle | ||
100V~240V AC，50/60Hz | 2.5° | ||
Input Power | Control | ||
350W@230V | International standard DMX 512 protocol, 5-pin interface | ||
Power factor PF>0.90 | 16channels in short mode and 20channels in standard mode | ||
Light Source | Housing | ||
Lamp Osram 7R (8000K,2000hrs) | High temperature and anti-UV ABS and aluminum , IP20 | ||
Prism/Frost | Net Weight | ||
| 1 16-facet prism, bi-directional rotation from slow to fast | 17.5Kg | ||
| both can be overlapped | |||
| Focus | Operation Temperature | ||
| DMX linear focus | Ambient temperature at maximum：45°C | ||
Dimmer /Strobe | Accessories | ||
Strobe at variable speeds(15 F.P.S at maximum) | Safety cord1 Pc | ||
| 0-100% linear dimmer | Clamp2 Pc | ||
Foldable clamp 2 Pc Optional | |||
Head Movement | User manual0 Pc QR code | ||
| Pan 540º, Tilt 270º with 16 bit control | |||
| Color Wheel | |||
1 color wheel：19 colors plus white（including 2 CTO and 1 CTB） | |||
Macros and bi-directional rainbow effects with variable speeds | |||
| a linear CYM color mixing system | |||
| Fixed Gobo | |||
1 fixed gobo wheel: 17gobos+open | |||
