| ELECTRIC PARAMETERS |
BEAM ANGLE |
||
|
Input voltage 200V~240V AC，50/60Hz |
0°～ 3.6° |
||
|
Input power 310W@220V |
|||
|
Power factor PF>0.90 |
CONTROL |
||
| MAX. Current: 1.5A @ 220V |
International standard DMX 512 protocol, 5-pin interface |
||
|
13channels in short mode ,14channels in standard mode and16 channels in extended mode |
|||
| THE SPECIFICATIONS OF THE LAMP |
Adjusting mode |
||
|
Osram SIRIUS HRI 231W |
|
||
| Color temperature 7900K |
OPERATION TEMPERATURE |
||
|
Rated life 2000hrs |
Maximum ambient temperature 40°C |
||
|
Energy save mode 2500hrs |
|||
|
OTHER FUNCTIONS |
|||
|
PRISM/FROST |
Adjustable Pan & Tilt speed |
||
|
1 8-facet prism(bi-directional rotation with variable speeds)+frost filter+open |
Lamp’s and fixture’s hours displayed | ||
|
Modular Structure for easy maintenance |
|||
|
FOCUS |
DMX512 wirless reciever |
||
| DMX linear focus |
Optional DMX512 Transmitter |
||
|
|
|||
| DIMMER/STROBE |
HOUSING |
||
|
0-100% linearly adjustable/ Double shutter blades, 0.3~25 F.P.S |
High temperature ABS, IP20 |
||
|
|
|||
|
HEAD MOVEMENT |
WEIGHT |
||
|
Pan 540º, Tilt 270º with 16 bit control |
14.5 kg |
||
| Color Wheel | |||
|
1color wheel: 14colors+ Open |
|||
|
rainbow effect with bi-directional and variable speeds |
|||
|
Stepping/linear color changing |
|||
|
|
|||
|
FIXED GOBO WHEEL |
|||
|
1 fixed gobo wheel: 17gobos+open |
|||
|
bi-directionally rotatable, and shakable at variable speeds |
|||
|
|
|||
