Input Voltage | Other Function | ||
100V~240V AC，50/60Hz | Total hours displayable | ||
English and Chinese menus | |||
Input Power | Built-in sensor diagnostic system | ||
770W@220V AC | Software versions displayable | ||
790W @ 100V AC | Input signal isolation | ||
Max. Current：8.0A @ 100V | Modular Structure for easy maintenance | ||
Power factor：PF>0.9 | Ethernet Interface | ||
DMX512 wireless reciever | |||
Light Source | |||
500W White LED (9000K, 20000hrs) | Housing | ||
CRI：Ra≥70( Option：Ra≥90) | High temperature ABS+ High tensile cast aluminum , IP66 | ||
CTO | Net Weight | ||
0-100% linear CTO | 39Kg | ||
Prism | Operation Temperature | ||
1pc of 4 facet prism , Bi-directional rotation with variable speeds and indexing function | Highest ambient temperature 45℃ | ||
Note: If the ambient temperature is below -20°C | |||
Frost | reset a projector before pre-heating it for more than 30 minutes | ||
1pc frost filter, linear frost effect( 0%-100%) | |||
Accessories | |||
Effect Wheel | Safety cord 2 Pc | ||
1pc, replaceable, bi-directional rotation with variable speeds | User manual 1 Pc | ||
Power Cable 1 Pc | |||
Focus | XLR connector 1 Set Male and female | ||
DMX linear Focusing | G clamps 2 pcs | ||
Ω clamps 2 pcs Optional | |||
Dimmer | |||
0-100% Linear adjustment | Control | ||
DMX512, 5 pin interfaces | |||
Strobe | RDM control protocol | ||
Double shutter blades, 0.3~25 F.P.S | 31channels in short mode,35 channels in standard mode and 50 channels in extended mode | ||
Master/Slave synchronized mode | |||
Pan And Tilt Movement | Stand-alone mode | ||
Tilt 0°~270° | |||
Pan 0°~540° | |||
Beam Angle | |||
linear zoom 5.5°～ 50° with 16 bit function | |||
| Color Wheel | |||
CMY linear mixing system with macros | |||
1 color wheel: 7exchangeable colors+ Open | |||
Half color effect, rainbow effect with bi-directional and variable speeds | |||
Stepping/linear color changing | |||
| Gobo | |||
1 Rotating Gobo Wheel: 8 replaceable gobos+ Open, Glass or Metal Gobo | |||
Bi-directional Rotation with variable speeds | |||
With Indexing Function | |||
Gobo Shake Effect with Variable Speeds | |||
Bi-directional Scrolling with Variable Speeds | |||
| Framing | |||
1framing module rotates between 0° and 90° and produces graphics of different shapes and sizes | |||
4 framing blades can produce full curtain effect | |||
