Input voltages |
Fan mode
|
||
|
100V~240V AC, 50/60Hz |
Standard mode and theater modes. Theater mode is quiet mode |
||
|
|
|||
|
Input Power |
Control |
||
|
550W @ 220V |
DMX512, 5 pin interfaces |
||
|
RDM protocol and DMX wireless control(optional sACN protocol) |
|||
|
Light source |
Ethernet Protocol |
||
|
350W, White LED module, CRI : Ra≥70 |
25channels in short mode, 30channels in standard mode, |
||
|
35channels in extended mode |
|||
|
CTO |
Master/Slave mode
|
||
|
Linear CTO (0-100%) |
Stand-Alone mode |
||
|
Master mode |
|||
|
Prism |
|||
|
1pc, 3-facet circular prism, bi-directional rotation at variable speeds, |
Other functions |
||
|
indexble. Other optional prisms are available. |
Adjustable Pan & Tilt speeds |
||
|
Pan and Tilt invertible and swappable |
|||
|
Frost |
Lamp’ s and fixture’ s hours displayed |
||
|
0-100% linear with 1pc frost filter |
Color touch Chinese/English screen, display invertible and touch keys |
||
|
Intelligently controllable fans |
|||
|
Focus |
Sensor diagnostic system |
||
|
DMX linear focus |
Input signal isolated, modular construction for easy |
||
|
maintenance, DMX channel voltages monitoring |
|||
|
Zoom |
Non-touchable magnetic sensor for positioning, |
||
|
DMX linear focus |
signal feedback, absolute position memory, auto-positioning |
||
|
after power-off or DMX signal disrtuption |
|||
|
Iris |
Firmware upgrade via DMX cable |
||
|
5-100% linear with macros |
Optional ethernet port
|
||
|
|
|||
|
Strobe |
Housing |
||
|
Electronic strobe 0.2~25 F.P.S, optional pulse, |
High temperature ABS, IP20 |
||
|
synchronized or non-synchronized strobe at slow, |
|||
|
medium and fast speeds |
Weight |
||
|
22Kg |
|||
|
Head movement |
|||
|
Pan 540º, Tilt 270º with auto position correction |
Ambient temperature |
||
|
Temperature at maximum 40°C |
|||
|
Beam angle |
|||
|
Beam/Spot Mode: 4°- 40° Linear Adjustment |
|||
|
Wash Mode: 5°- 45° Linear Adjustment |
|||
|
With 16 bit control function |
|||
| CMY | |||
|
CMY color mixing system with macros |
|||
| 1 Color Wheels | |||
|
1 Color wheel: 12colors+ Open, |
|||
|
rainbow effect with bi-directional and variable speeds, |
|||
|
Stepping/linear color changing |
|||
| Fixed Gobo | |||
|
1 Fixed gobo wheel: 7 gobos +Animation Effect+Open |
|||
|
Bi-directionally rotatable, and shakable at variable speeds |
|||
| Rotating Gobo | |||
|
1 Rotating gobo wheel:7 Rotating Gobos +Open |
|||
|
Bi-directionally rotatable, and shakable at variable speeds |
|||
