Input voltage |
a single fixture or multiple ones and store brightness |
||
|
100V-240V AC，50/60Hz |
values into the fixtures |
||
|
|
|||
|
Input power |
CRI mode | ||
|
1900W @ 220V |
Running at high CRI mode via DMX channel to ensure high CRI optical effect |
||
|
|
|||
| Light sources |
Control |
||
|
1500W white LED module (6500K) |
International standard DMX512 signal and RDM function |
||
| CRI : Ra≥95、R9≥95, Lamp Life : ≥20000hrs |
31channels in short mode, 35channels in standard mode,49channel in extended mode |
||
|
DMX512 wireless control |
|||
| Cto |
Art Net protocol（optional） |
||
|
Linear CTO system(0-100%, 1800K-6500K) |
sACN protocol(optional) |
||
|
Beam angle |
Control Interface | ||
|
1/2θ（peak）:7°～40°, with 16 bit precision |
DMX512 ports（5-pin） |
||
|
1/10θ（peak）:12°～60°, with 16 bit precision |
Ethernet port RJ45 |
||
|
|
|||
| Focus |
Other functions |
||
|
DMX linear focus |
Pan and Tilt speeds adjustable，Pan and Tilt swappable and invertible |
||
|
High precision magnet sensor for positioning |
|||
|
Dimmer |
3.2-inch touch color screen, Chinese and English menus |
||
|
Linear electronic dimmer 0-100% with 16 bit control |
Screen automatic lock –up while standby |
||
|
3 dimmer speeds |
Error diagnostic system with sensors | ||
|
4 dimmer gamma curves |
Smart fan cooling system |
||
|
Dimmer frequency(1.2K-25K) adjustable, suitable for 4K high speed video camera |
Display of fixture hours and software versions |
||
|
Modular construction for easy maintenance |
|||
|
Strobe |
Isolated input signals |
||
|
Electronic strobe, 0.3~25 F.P.S, optional synchronized or non-synchronized strobe |
Firmware update via DMX cable |
||
|
|
|||
|
Head movement |
IP rating |
||
|
Pan 540º, Tilt 270º with auto position correction and 16 bit control |
IP20 |
||
|
|
|||
|
Advanced macros |
Operation temperature |
||
|
Color temperature macros: optional 2700K,3000K,3500K,4000K,4500K,5000K,5700K |
Ambient temperature at maximum：45°C |
||
|
Standard color macros: 89 color options based on standard color chart |
|||
|
|
|||
|
Fan mode |
Weight |
||
|
Standard mode and theater modes.Theater mode is quiet mode |
Net weight 43.5 KG |
||
|
|
|||
|
Brightness calibration function |
|||
|
With brightness calibration function to calibrate initial brightness for |
|||
| CMY | |||
|
CMY linear coloring mixing system with macros |
|||
| 2 Color Wheels | |||
|
Color Wheels 1：Red, Green, Blue, Orange , Pink, Light cyan,+ open |
|||
|
Color Wheels 2：Dark Red, Amber, Tea red, Apple Green, Dark Magenta, UV+ open |
|||
|
Full color/half color/linear color |
|||
|
Bi-directional rainbow effect with variable speeds |
|||
| Framing | |||
|
1 Framing module |
|||
|
4 framing blades to make graphics with different sizes and shapes |
|||
|
Framing module rotates bi-directionally up to 360 °and continually, each framing blade produces full curtain effect |
|||
