Input voltages | Fan mode | ||
100V~240V AC, 50/60Hz | Standard mode and theater modes. Theater mode is quiet mode | ||
Input Power | Control | ||
550W @ 220V | DMX512, 5 pin interfaces | ||
RDM protocol and DMX wireless control(optional sACN protocol) | |||
Light source | Ethernet Protocol | ||
350W, White LED module,(9000K, 20000hour, CRI : Ra≥70) | 35channels in short mode, 40channels in standard mode | ||
53channels in extended mode | |||
CTO | Master/Slave mode | ||
Linear CTO system(0-100%, 9000K-1800K) | Stand-Alone mode | ||
Master mode | |||
Prism | |||
1pc, 3-facet circular prism, bi-directional rotation at variable speeds | Other functions | ||
indexing. Other optional prisms are available | Adjustable Pan & Tilt speeds | ||
Pan and Tilt invertible and swappable | |||
Frost | Lamp’ s and fixture’ s hours displayed | ||
Wash effect | Color touch Chinese/English screen, display invertible and touch keys | ||
Intelligently controllable fans | |||
Focus | Sensor diagnostic system | ||
DMX linear focus | Input signal isolated, modular construction for easy maintenance | ||
DMX channel voltages monitoring | |||
Zoom | Non-touchable magnetic sensor for positioning | ||
DMX linear focus | signal feedback, absolute position memory, auto-positioning | ||
| after power-off or DMX signal disrtuption | |||
| Dimmer | Firmware upgrade via DMX cable | ||
0-100% linear with dimming | Optional ethernet port | ||
Iris | Housing | ||
5-100% linear with macros | High temperature ABS, IP20 | ||
Strobe | Weight | ||
Electronic strobe 0.2~25 F.P.S, optional pulse, | 22.6Kg | ||
synchronized or non-synchronized strobe at slow, | |||
medium and fast speeds | Ambient temperature | ||
Temperature at maximum 45°C | |||
Head movement | |||
Pan 540º, Tilt 270º with auto position correction | |||
Beam angle | |||
Beam/Spot Mode: 4°- 40° Linear Adjustment | |||
Wash Mode: 5°- 45° Linear Adjustment | |||
With 16 bit control function | |||
| 【Version：20240628】 | |||
| CMY | |||
CMY color mixing system with macros | |||
| 1 Color Wheels | |||
1 Color wheel: 12colors+ Open, | |||
rainbow effect with bi-directional and variable speeds, | |||
Stepping/linear color changing | |||
| Rotating Gobo | |||
1 Rotating gobo wheel:7 Rotating Gobos +Open | |||
Bi-directionally rotatable, and shakable at variable speeds | |||
| Framing | |||
1 Framing Module: 4 Framing Blades | |||
Framing Module continual rotation with many graphics of different sizes and shapes | |||
4 Framing blades to make full curtain effect | |||
