Input voltage | Control | ||
100V~240V AC，50/60Hz | International standard DMX 512 signal ,5-pin XLR connectors | ||
Short Mode15 channels，standard Mode 17channels | |||
Power consumption | extended mode 18channels | ||
650W @ 220V | Self test mode | ||
| Light sources | Other functions | ||
| 500W laser module(9500K,12000hrs) | Pan and Tilt speeds adjustable | ||
Lamp hours and fixture hours displayed | |||
| Prism/frost | Modular construction easy for maintenance | ||
3 prism wheels: (an 8-facet circular prism+ a 4-facet linear prism) | Wireless receiver | ||
+ (a 16-facet circular prism + a frost filter) | Wireless transmitter(Optional) | ||
prisms overlapped. Other prism options available | ArtNet and sACN(Optional) | ||
Focus | Housing and ingress protection | ||
| DMX linear focus | Cast aluminum and high temperature and UV resistant ABS with IP66 | ||
Strobe/Dimmer | Weight | ||
Double flag strobe,0.3-25 F.P.S. / linear dimmer | Net weight:39.2 Kg | ||
Movements | Operation temperature | ||
Pan (0°-540°),Tilt( 0°-270°) with auto positioning correction function | -20°C-45°C | ||
Note: If the ambient temperature is below 0°C, preheat the fixture for some time | |||
Beam angle | (less than 20 min based on actual situation normally) before striking the light source | ||
Beam angle: 0.8° | |||
| 【Versio：20240701】 |
| Color Wheel | |||
1 color wheel: 19 colors + open | |||
Macros and bi-directional rainbow effects with variable speeds | |||
| Fixed Gobo | |||
1 fixed gobo wheel：30 gobos | |||
Shakable at variable speeds and bi-directional rotation at variable speeds | |||
