Electric parameters：Movements：
Input voltage: 100V~240V AC，50/60Hz Pan (0°-540°)，Tilt( 0°-270°) with auto positioning correction function
Power consumption: 450W @ 220V
Rated current: 5 A @ 220V Beam angle：
Power factor: PF>0.9 Beam angle：0.6°
Light sources：Control：
Light sources 300 W RGB laser engine International standard DMX 512 signal,3pin XLR connectors(optional 5-pin)
Color temperature 7500K
Rated life ≥20000hrs Other functions：
Lumens ≥10000lm Pan and Tilt speeds adjustable
Nominalwavelengthofredlaser 638nm DMX, Art-Net and sACN protocols
Nominalwavelengthofgreenaser 520nm
Nominalwavelengthofbluelaser 450nm Housing and ingress protection：
Initial beam’s diameter 80~120mm Cast aluminum and high temperature and UV resistant ABS with IP65
Prism： Weight：
2 set prism Net weight：21Kg
Frost：Ambient temperature：
1 pc of frost filter 45 °C at maximum
Note: while ambient temperature below zero, please preheat a fixture for Focus some time(normally less than 20 minutes) based on actual on the
DMX linear focus temperature before turning laser engine.
Strobe/dimmer
Double flag strobe，0.3-25 Hz/ linear dimmer
【Version：20250226】
1 fixed gobo wheel: 13gobos + open
Shakable at variable speeds and bi-directional rotation at variable speeds
