| ELECTRIC PARAMETERS Input voltage : 200V~240V AC，50/60Hz Input power : 1800W@220V Power factor: PF>0.9 THE SPECIFICATIONS OF THE LIGHT SOURCE(WITH 1400W BALLAST AND IGNITER) OSRAM : lok-it 1400/PS Color temperature : 6000K CRI : >95 Lamp stand : single ended Rated life : 750hrs CTO 0-100% linear CTO PRISM 1pc of 3 facet prism , Bi-directional rotation with variable speeds and indexing function FROST 1pc frost filter, linear frost effect EFFECT WHEEL 1pc, replaceable, bi-directional rotation with variable speeds FOCUS DMX linear Focusing DIMMER 0-100% Linear adjustment IRIS 5-100% linear adjustment with macros |
STROBE Double shutter blades, 0.3~25 F.P.S HEAD MOVEMENT Pan 540º, Tilt 270º with auto position correction BEAM ANGLE linear zoom 6°～ 55°with 16 bit function CONTROL DMX512, 5 pin interfaces RDM control protocol 28channels in short mode, 32channels in standard mode and 39channels in extended mode Self-test mode OTHER FUNCTION Adjustable Pan & Tilt speed Lamp and Total hours displayed Touch screen English and Chinese Display with Contrast and brightness adjustable Energy saving ballast Built-in sensor diagnostic system Input signal isolation Modular Structure for easy maintenance Ethernet Interface DMX512 wireless reciever DMX512 Transmitter( Optional) ArtNet and sACN ( Optional) HOUSING High temperature ABS, IP20 NET WEIGHT 48Kg OPERATION TEMPERATURE Ambient temperature at maximum：40°C |
