| ELECTRIC PARAMETERS Input voltages : 100V~240V AC，50/60Hz Input Power : 850W @ 220V Power factor : PF〉0.95 Max. Current: 3.9 A @ 220V LIGHT SOURCE SPECIFICATIONS Power consumption : 700W, White LED module Color Temperature : 8000K Manufacturers Rated Lamp Life : >20000hour CRI : Ra ≥ 70 CTO Linear CTO system(0-100%, 1800K-6500K) EFFECT WHEEL Bi-directional rotation at variable speeds IRIS 5-100% linear with macros PRISM 1pc, 3-facet circular prism, bi-directional rotation at variable speeds with indexing function FROST 1 frost filter ,0-100% linear BEAM ANGLE 5°～60°,linear with 16 bit control FOCUS DMX linear with auto focus function DIMMER Linear electronic dimmer 0-100% with 16 bit control 3 dimmer speeds 5 dimmer curves Dimmer frequency(1.2K-25K) good for 4K high speed video camera STROBE Electronic strobe 0.3~25 Hz, optional pulse, synchronized or non-synchronized strobe at slow, medium and fast speeds HEAD MOVEMENT Pan 540º, Tilt 270º with auto position correction and 16 bit control ADVANCED MACROS Color temperature macros: optional 2700K,3000K,3500K,4000K,4500K,5000K,5700K Standard color macros: 89 color options based on standard color chart. |
FIXED TYPE Including moving head light, fixed-focus profile light, zoom profile light Moving head light with beam angle range(5-60°) Fixed focus profile light with beam angle options including 5°,10°,19°,26°,36°,60° Zoom profile light with beam angle ranges including 5-15°,15-35°,35-60° (Note: Auto quiet theater mode for fixed focus profile light and zoom profile light) FAN MODE Standard and theater modes. Theater mode is quiet mode BRIGHTNESS CALIBRATION FUNCTION With brightness calibration function to calibrate initial brightness for a single fixture or multiple ones and store brightness values into the fixtures CRI MODE Running at high CRI mode via DMX channel to ensure high CRI optical effect. CONTROL International standard DMX512 signal and RDM function 31channels in short mode, 36channels in standard mode,41channel in extended mode Art Net protocol(optional) , sACNprotocol(optional), DMX512 wireless control Master/Slave mode Standalone mode Master Mode CONTROL INTERFACE DMX512 ports（5-pin） Ethernet port RJ45 OTHER FUNCTIONS Adjustable Pan & Tilt speeds Pan and Tilt invertible and swappable Light source’s and fixture’s hours displayed LCD color Chinese/English screen, display invertible and touch keys Intelligently controllable fans Sensor diagnostic system Input signal isolated modular construction for easy maintenance DMX channel voltages monitoring Non-touchable magnetic sensor for positioning, signal feedback, absolute position memory, auto-positioning after power-off or DMX signal disrtuption Firmware upgrade via DMX cable Optional ethernet port HOUSING High temperature ABS, IP20 NET WEIGHT 23.6Kg AMBIENT TEMPERATURE Temperature at maximum 45°C |
| 【Version：20251031】 |
