| ELECTRICAL PARAMETERS Input voltage: 100V-240V AC，50/60Hz Input power: 2100W@220V Power factor: PF>0.95 Current at maximum: 9.5A @ 220V OPTICAL SYSTEM Light sources : 1800W white LED module Colour Temperature : 8000K CRI : Ra≥95、R9≥95 High out version : Ra ≥70 Manufacturers Rated Lamp Life : ≥20000hrs CTO Linear CTO system(0-100%, 1800K-6500K) EFFECT WHEEL 1 animation effect wheel, bi-directional rotation with varied speeds IRIS Linear iris 5-100% with macros PRISM 1pc of 4-facet circular prism+1 pc of linear prism, bi-directional rotation with varied speeds with indexing function FROST 2 frost filters: 1 heavy frost filter + 1 light frost filter (0-100% linear ) BEAM ANGLE Linear zoom 6°-54°with 16 bit precision FOCUS Linear focus with auto-focus function DIMMER Linear electronic dimmer 0-100% with 16 bit control 3 dimmer speeds 5 dimmer gamma curves Dimmer frequency(1.2K-25K) STROBE Electronic strobe, 0.3~25 Hz, optional synchronized/ non-synchronized strobes HEAD MOVEMENT Pan 540º, Tilt 270º with auto position correction and 16 bit control ADVANCED MACROS Color temperature macros: optional 2700K,3000K,3500K,4000K,4500K,5000K,5700K Standard color macros: 89 color options FAN MODE Standard mode and theater modes. Theater mode is quiet mode |
FIXTURE TYPES
Including moving head light, fixed-focus profile light, zoom profile light Moving head light with beam angle range(6-54°) Fixed focus profile light with beam angle options including 6°,10°,19°,26°,36°,54° Zoom profile light with beam angle ranges including 6-15°,15-35°,35-54° (Note: Auto quiet theater mode for fixed focus profile light and zoom profile light) BRIGHTNESS CALIBRATION FUNCTION With brightness calibration function to calibrate initial brightness for a single fixture or multiple ones and store brightness values into the fixtures CRI MODE Running at high CRI mode via DMX channel to ensure high CRI optical effect. CONTROL International standard DMX512 signal and RDM function 47channels in short mode, 52channels in standard mode,67channel in extended mode Art Net protocol , sCAN protocol(optional), DMX512 wireless control CONTROL INTERFACE DMX512 ports（5-pin） Ethernet port RJ45 OTHER FUNCTIONS Pan and Tilt speeds adjustable Pan and Tilt swappable and invertible High precision magnet sensor for positioning 3.2-inch touch color screen, Chinese and English menus, Screen automatic lock –up while standby Error diagnostic system with sensors Smart fan cooling system Display of fixture hours and software versions Modular construction for easy maintenance Isolated input signals Firmware update via DMX cable port IP RATING IP20 OPERATION TEMPERATURE 45℃ at Maximum WEIGHT Net weight 47.8Kg Cardboard box(mm)(L*W*H) 815*615*810( 1pc/case ) Flight case(mm) (L*W*H) 765*665*895( 1pc/case ) |
|
【Version:20260528】
|
