| Input voltage |
Head movement |
||
|
208V-240V AC，50/60Hz |
Pan 540º, Tilt 270º with auto position correction |
||
|
|
|||
|
Rated power |
Beam angle |
||
|
1800W@220V |
linear zoom 6°～55°with 16 bit function |
||
|
Light source |
Control | ||
|
OSRAM lok-it 1400/PS |
DMX512 5 pin interfaces | ||
|
Color temperature: 6000K |
RDM control protocol |
||
|
CRI: >90 |
33channels in short mode, 36channels in standard mode |
||
|
lamp stand: single ended |
and 52channels in extended mode ,Self-test mode |
||
|
rated life: 750hrs |
|||
|
CTO |
Other functions |
||
|
0-100% linear CTO |
Adjustable Pan & Tilt speed |
||
|
Lamp and Total hours displayed |
|||
|
Prism |
LCD English and Chinese Display with Contrast and brightness adjustable |
||
|
1pc of 3 facet prism |
Energy saving ballast |
||
| Bi-directional rotation with variable speeds and indexing function |
Built-in sensor diagnostic system |
||
|
Input signal isolation |
|||
|
Frost |
Modular Structure for easy maintenance |
||
|
1pc frost filter, linear frost effect |
Ethernet Interface |
||
|
DMX512 wirless reciever, DMX512 Transmitter ( Optional) |
|||
|
Focus |
ArtNet and sACN (Optional) |
||
|
DMX linear Focusing |
Fan mode: Standard/ Theater |
||
|
Dimmer |
Housing |
||
|
0-100% Linear adjustment |
High temperature ABS, IP20 |
||
|
Iris |
Net weight |
||
|
5-100% linear adjustment with macros |
48Kg | ||
|
Strobe |
Operation temperature |
||
|
Double shutter blades, 0.3~25 F.P.S |
Highest ambient temperature 40°C |
||
| 【Version：20231108】 | |||
| CMY | |||
|
CMY linear mixing system with macros |
|||
| Color Wheel | |||
|
1 Color wheel: 7colors+ Open |
|||
|
Half Color effect,Rainbow effect with bi-directional and variable speeds
|
|||
|
Stepping/linear color changing |
|||
|
Fixed Gobo |
|||
|
1 Fixed Gobo Wheel: 4 replaceable gobos+ Dynamic effect+open |
|||
|
Gobo Shake Effect with variable speeds, bi-directional scrolling with variable speeds |
|||
|
Dynamic waves and fire effects combined with rotating gobos |
|||
|
Rotating Gobo |
|||
|
1 Rotating Gobo Wheel: 6 replaceable gobos+ White |
|||
|
Glass or Metal Gobo， Bi-directional Rotation with variable speeds |
|||
|
With Indexing Function |
|||
|
Gobo Shake Effect with Variable Speeds |
|||
|
Bi-directional Scrolling with Variable Speeds |
|||
|
1 Framing Module: 4 Framing Blades |
|||
|
Framing Module continual rotation with many graphics of different sizes and shapes |
|||
|
4 Framing blades to make full curtain effect |
|||
