PR-6000 Wash/Framing
Model No.PR-2926
PR-6000 Wash/Framing
PR-6000Wash/Framing(1400W)is a moving head fixture with highly photoelectic efficiency,low noise and mutipile functions including Wash and Framing. It is with Osram Lok-it 1400/PS lamp, optical design with wide zoom range, 200mm front lens, beam angle(10°~60°),primary and secondary reflectors, resulting in very intensive and high CRI beam, and linear color mixing system of CMY+CTO and plenty of effects by double color wheels. The convenient, fast, easy and unique invented technology which is 360 ° continually rotating framing system can position at any angle precisely and solve a big internationally difficult problem of not having continually rotating framed images faced by the light designers.
Features
Colors
Download
ELECTRICAL PARAMETER
Input voltage    200V~240V AC,50/60Hz
Input power   1800W@220V
Power Factor:PF >0.9

Specifications of light source(with 1400W ballast and igniter)
Osram                  Lok-it 1400/PS
Color temperature         6000K
CRI                    90
Ceramic stand            single-ended
Rated life                750hrs

CTO
0-100% linearCTO system

FOCUS
DMX linearfocus

DIMMER
0-100% linear adjustment

STROBE
Double shutter blades, 0.3~25 F.P.S

HEADMOVEMENT
Pan 540º,Tilt 270º with auto position correction

BEAMANGLE
linear zoom 10°~ 60°with 16 bitfunction
CONTROL
DMX512, 3 pin and 5 pin interfaces
RMD control protocol
27channelsin shortmode, 32channelsin standardmode and 45channelsin extendedmode
Self-testmode

OTHER FUNCTIONS
AdjustablePan&Tiltspeed
Lamp and Total hours displayed
LCD English andChinese DisplaywithContrast and brightness adjustable
Energy saving ballast
Built-in sensor diagnostic system
Inputsignal isolation
ModularStructure for easymaintenance
EthernetInterface
DMX512wirelessreciever
DMX512Transmitter ( Optional)
ArtNet and sACN ( Optional)

HOUSING
High temperatureABS, IP20

NETWEIGHT
46Kg

OPERATIONTEMPERATURE
Ambient temperature atmaximum:40°C




  【Version:20250912】



CMYcolormixing withmacros
2 color wheels:each with 7 colors+ open
Half color effect, bi-directionalrotationwith varied speedsforrainbow effect
Stepping/Linear color changing
Name
Description
Download
Specification
PR-2926 Version:20250912
User manual
PR-2926 Version:20250912
