Light Source
|
| Channels
|
|
| OSRAM 19x40W LEDs(4-in-1, RGBW), 50,000 hrs | 14/20/94/101 DMX channels USITT DMX-512
|
|
|
|
Input Voltages
|
| Other Functions
|
|
AC100-240V, 50/60Hz
|
| 2.4" TFT LCD display, RDM, wireless control and Art-NET(optional)
|
|
|
|
|
Power Consumption
|
| Housing
|
|
| 960W |
| Moulded fire proof ABS PC
|
|
| IP65
|
|
Strobe:
|
|
|
|
| 1-25T/sec high speed shutter/strobe effect with variable speed | Net Weight
|
|
| 24kg
|
|
Dimmer
|
|
|
|
| 0-100% smooth linear LED dimming with fine control(4 Dimming curves) |
|
|
|
|
|
| Effect |
|
|
|
Pixel mapping capability with each LEDs controllable individually
|
|
|
|
|
|
Light Angle
|
|
|
|
5° ~ 60°
|
|
|
|
|
|
|
Head Movement
|
|
|
|
8/16 bit smooth and precise resolution for pan 540° /tilt 270° movement
|
|
|
|
|
|
|
Control
|
|
|
|
DMX512, master-slave, and sound activated controllable or auto operation
|
|
|
