Input Voltage | Beam Angle | ||
200V~240V AC，50/60Hz | 0°～ 2° | ||
Input Power | Control | ||
600W@230V | International standard DMX 512 protocol, 5-pin interface | ||
Power factor PF>0.90 | 14channels in short mode and 16channels in standard mode | ||
Light Source | Housing | ||
MSD Platinum 300S Flex (7800K,6000hrs) | High temperature and anti-UV ABS and aluminum , IP20 | ||
Colors | Net Weight | ||
1color wheel: 14colors+ Open | 17Kg | ||
Fixed Gobo Wheel | Packaging | ||
1 fixed gobo wheel: 17gobos+open, gobo diameter=6mm, its thickness=0.8mm | Standard: carton 440x360x710(mm) | ||
Optional: flight case 760x450x810(mm), 2 in 1 | |||
Prism/Frost | |||
1 8-facet prism and 1 16-facet prism | Operation Temperature | ||
| bi-directional rotation from slow to fast , both can be overlapped | Ambient temperature at maximum：45°C | ||
Focus | Accessories | ||
DMX linear focus | Safety cord1 Pc | ||
Clamp2 Pc | |||
Dimmer /Strobe | Foldable clamp 2 Pc Optional | ||
Strobe at variable speeds(15 F.P.S at maximum) | User manual0 1 Pc | ||
0-100% linear dimmer | |||
Head Movement | |||
Pan 540º, Tilt 270º with 16 bit control | |||
| Color Wheel | |||
1color wheel: 14colors+ Open | |||
| Fixed Gobo | |||
1 fixed gobo wheel: 17gobos+open, gobo diameter=6mm, its thickness=0.8mm | |||
