| Input voltage | Beam angle | ||
100V~240V AC，50/60Hz | 0°～2.3°, Linear zoom | ||
Input power | Control | ||
550W@100V,500W@220V | DMX512 and 5 pin interfaces | ||
17channels in short mode, 19channels in standard mode 21 channels in extended mode | |||
Light Source | Adjustable mode | ||
Phlips MSD Platinum Flex 300S(7800K, 6000hrs) | |||
| Other functions | |||
Prism/Effect wheel | Adjustable Pan & Tilt speed | ||
| 3Prisms: standard: individual 8-facet prism; | Fixture and lamp usage time display | ||
16-facet prism+ linear prism+ Frost + Open | Modular construction for easy maintenance | ||
(bi-directional rotation) | DMX512 wireless receiver | ||
(Optional 3-16 facet prism or gradient prism) | DMX512 wireless transmitter (optional) | ||
Focus | Housing | ||
| 0-100% linearly adjustable by DMX | Composite plastic, IP20 | ||
Strobe | Weight | ||
Double shutter blades, 0.3~20 F.P.S | 18 Kg | ||
Head movement | |||
Pan 540º, Tilt 270º with auto position correction | |||
