Input Voltages |
Control |
||
|
100V~240V AC，50/60Hz |
International Standard DMX512 signal |
||
|
|
5 pin DMX512 interfaces |
||
|
Input Power |
RDM protocol |
||
|
900W @ 220V AC |
24 channels in short mode |
||
|
Power factor: PF〉0.9 |
31channels in standard mode |
||
|
|
and 41 channels in extended mode |
||
|
Light Source |
Master/slave synchronized mode |
||
|
40W(RGBW IN ONE, 19pcs, 50000 hrs) |
Stand-alone mode, Preset mode |
||
|
Optional Ra≥90 |
DMX 512 Wireless control |
||
|
|
ArtNet and sACN(optional) |
||
|
|
|
||
|
Head Movement |
Other Functions |
||
|
Pan: 540°(16 bit control) |
Color touch display, English/Chinese menus |
||
|
Tilt: 240°(16 bit control) |
Display auto-lock while standby to avoid unintended touch |
||
|
Pan and Tilt invertible and |
Pan and Tilt speeds adjustable |
||
|
swappable with auto-positioning function |
Pan and Tilt invertible and |
||
|
|
swappable |
||
|
Colors |
Over temperature protection |
||
|
RGBWlinear color mixing with built-in macros |
Fixture time and DMX 512 channel value displayed |
||
|
Color Temperature macros: |
Software versions displayed, display invertible |
||
|
Color Temperature macros: |
Sensor diagnostic system |
||
|
optional 2700K、3000K、3500K、4000K |
Intelligent fan cooling system |
||
|
4500K、5000K、5700K |
Input signal insulated |
||
|
Color Macros: 89 color options included in standard color chart |
Firmware upgrade via DMX cable |
||
|
|
Smart color managementsystem(optional) |
||
|
|
|
||
|
Dimmer |
Housing |
||
|
Electronic dimmer,0-100% linear(16Bit control) |
High temperature ABS, IP20 |
||
|
3 dimmer speeds |
|
||
|
5 dimmer curves |
Ambient Temperature |
||
|
Dimmer frequency 1.2K~2.5K adjustable |
Ambient temperature 45°C at maximum |
||
|
for high speed 4K video cameras |
|
||
|
|
|
||
|
Color Temperature |
Weight |
||
|
Color Temperature 1800K-10000K |
13.2Kg |
||
|
linear control |
|
||
|
|
|
||
|
Strobe |
Accessories |
||
|
Electronic strobe, 0.3-25 F.P.S. |
G Clamp 2 Pcs |
||
|
with built-in pulse strobe |
XLR Cable 1 Pc With plug and socket |
||
|
|
Safety Cord 1 Pc |
||
|
Beam Angle |
User Manual 0 Pc QR Code |
||
|
Beam Angle(1/2 peak)θ1/2: 4 °~40° |
|
||
|
Field Angle(1/10 Peak)θ: 7°~60° |
|
||
|
|
|
||
|
Fan Mode |
|
||
|
Standard mode and theater modes |
|
||
|
Theater mode is quiet mode |
|
||
|
|
|
|
|
|
|
|
【Version：20241022】 |
|
