ELECTRIC PARAMETERS
Rate voltage :100V~240V AC，50/60Hz
Input power :1425W@110V
1400W @ 220V AC
Nominal current: 6A @ 220V AC
Power factor : PF>0.9
BTU/hrs (+/- 10%) 2387
THE SPECIFICATIONS OF THE LIGHT SOURCE
RGBL LED 19X60W
RGB LED 76X0.5W
Rated life: 50000hrs
EFFECTS
Motorized zoom
Linear color temperature (2000 -8000K)
RGBL color mixing and pixel control
Secondary RGB LEDs mapping
Color macros
Electronic strobe and dimmer curve options
16 bit dimmer
CONTROL/CONNECTIONS
26/98/251/321 DMX channel modes
Pan：540°
Tilt：205°
LED refresh rates (800 - 24000 Hz)
Full color and invertible LCD display
RDM support
IP65 5-pin XLR DMX input/output
IP65 RJ45 Ethernet input/output(Art-Net,sACN)
IP65 rated power cord
HOUSING AND INGRESS PROTECTION
Cast aluminum and High temperature and UV resistant ABS, IP65
