Electric parameters

Input voltage: 100V~240V AC，50/60Hz
Power consumption: 450W @ 220V
Rated current: 5 A @ 220V
Power factor: PF>0.9

Light sources

Light sources                 300 W RGB laser engine

Color temperature         7500K

Rated life                       ≥20000hrs

Lumens                          ≥10000lm

Nominalwavelengthofredlaser      638nm

Nominalwavelengthofgreenaser   520nm

Nominalwavelengthofbluelaser     450nm

Initial beam’s diameter                80~120mm

Prism：

2 set prism

Frost

1 pc of frost filter

Focus

DMX linear focus

Strobe/dimmer

Double flag strobe，0.3-25 Hz/ linear dimmer

Movements

Pan (0°-540°)，Tilt( 0°-270°) with auto positioning correction function

Beam angle

Beam angle：0.6°

Control

International standard DMX 512 signal,3pin XLR connectors(optional 5-pin)

Other functions

Pan and Tilt speeds adjustable

DMX, Art-Net and sACN protocols

Housing and ingress protection

Cast aluminum and high temperature and UV resistant ABS with IP65

Weight

Net weight：21Kg

Ambient temperature

45 °C at maximum

Note: while ambient temperature below zero,  please preheat a fixture for some time(normally less than 20 minutes) based on actual temperature before turning on the laser engine.

【Version：20250226】
