Electric parameters

Input voltage: 100V~240V AC，50/60Hz

Power consumption: 660W @ 220V

Rated current: 3.0A/220V

Power factor: PF>0.9

Light sources

Light sources：500W laser module

Color temperature：9500K

Rated life：12000hrs

Prism/frost：

2 prism wheels: 1 wheel (an 8-facet circular prism+ a 4-facet linear prism )

+1 wheel (a 9-facet circular prism + a gradient prism), prisms can be overlapped. Other prism options available.

Frost

1 pc frost filter

Focus

DMX linear focus

Strobe/Dimmer

Double flag strobe，0.3-25 F.P.S. / linear dimmer

Movements

Pan (0°-540°)，Tilt( 0°-270°) with auto positioning correction function

Beam angle

Beam/Spot mode angle：0.8°-26°

Wash mode : 1.8°-30°

Unique super wide angle/under wash mode : 38°-60°

Control

International standard DMX 512 signal ,5-pin XLR connectors

Short Mode 23 channels，standard Mode 28 channels, extended mode 31 channels

Self test mode

Other functions

Pan and Tilt speeds adjustable

Lamp hours and fixture hours displayed

Modular construction easy for maintenance

Wireless receiver

Wireless transmitter  ( Optional)

ArtNet control( Optional)

Housing and ingress protection

Cast aluminum and high temperature and UV resistant ABS with IP66

Weight

Net weight：37.8Kg

Ambient temperature

45 °C at maximum

Note: If the ambient temperature is below 0°C, preheat the fixture for some time( less than 20 min based on actual situation normally) before striking the light source

【Version：20241125】
