ELECTRIC PARAMETERS

Input voltages : 100V~240V AC，50/60Hz

Input Power :   950W @ 220V

Power factor :    PF〉0.95

Max. Current:  4.3 A @ 220V

LIGHT SOURCE  SPECIFICATIONS(Yellow)

Power consumption :  700W, White LED module

Color Temperature :   6500K

Manufacturers Rated Lamp Life : 20000hour

CRI : Ra≥70

CTO

Linear CTO system(0-100%, 1800K-6500K)

EFFECT WHEEL

Bi-directional rotation at variable speeds

IRIS

5-100% linear with macros

PRISM

1pc, 3-facet circular prism, bi-directional rotation at variable speeds with indexing function

FROST

1 frost filter ,0-100% linear

BEAM ANGLE

5°～60°,linear with 16 bit control

FOCUS

DMX linear with auto focus function

DIMMER

Linear electronic dimmer 0-100% with 16 bit control

3 dimmer speeds

4 dimmer curves

Dimmer frequency(1.2K-25K) good for 4K high speed video camera

STROBE

Electronic strobe 0.2~25 Hz, optional pulse, synchronized or non-synchronized strobe at slow, medium and fast speeds

HEAD MOVEMENT

Pan 540º, Tilt 270º with auto position correction and 16 bit control

Advanced macros

Color temperature macros: optional 2700K,3000K,3500K,4000K,4500K,5000K,5700K

Standard color macros: 89 color options based on standard color chart.

Fixture types

Including moving head light, fixed-focus profile light, zoom profile light

Moving head light with beam angle range(5-60°)

Fixed focus profile light with beam angle options including 5°,10°,19°,26°,36°,60°

Zoom profile light with beam angle ranges including 5-15°,15-35°,35-60°

(Note: Auto quiet theater mode for fixed focus profile light and zoom profile light)

Fan mode

Standard mode and theater modes.  Theater mode is quiet mode

Brightness calibration function

With brightness calibration function to calibrate initial brightness for a single fixture or multiple ones and store brightness

values into the fixtures

CRI mode

Running at high CRI mode via DMX channel to ensure high CRI optical effect.

CONTROL

International standard DMX512 signal and RDM function

40channels in short mode, 46channels in standard mode,59channel in extended mode

Art Net protocol(optional) , sACNprotocol(optional), DMX512 wireless control

Master/Slave mode

Standalone mode

Master Mode

CONTROL INTERFACE

DMX512 ports（5-pin）

Ethernet port RJ45

OTHER FUNCTIONS

Adjustable Pan & Tilt speeds

Pan and Tilt invertible and swappable

Lamp’s and fixture’s hours displayed

Color touch Chinese/English screen, display invertible and touch keys

Intelligently controllable fans

Sensor diagnostic system

Input signal isolated, modular construction for easy maintenance, DMX channel voltages monitoring

Non-touchable magnetic sensor for positioning, signal feedback, absolute position memory, auto-positioning after power-off or DMX signal disrtuption

Firmware upgrade via DMX cable

Optional ethernet port

HOUSING

High temperature ABS, IP20

NET WEIGHT

24.2Kg

AMBIENT TEMPERATURE

Temperature at maximum 45°C

【Version：20250217】
