| Light Source | Channels | ||
| OSRAM 19x60W LEDs(RGBW, 4 in 1), 2700K~10000K, 50000 hrs |
26channels in short mode, 30channels in standard mode，and 102 channels in extended mode |
||
| Input Voltages | Other Functions | ||
| 100V~240V AC, 50/60Hz | Pixel Control | ||
|
Bi-directional and continual rotation of the front lens panel |
|||
| Power Consumption | Color touch screen and its brightness adjustable | ||
| 1400W@230V |
Wireless Control(Optional) |
||
|
Pan and Tilt Speed adjustable and Pan and Tilt can be inverted |
|||
| Strobe | Firmware upgraded via DMX interface and XLR cable | ||
|
Electronic strobe:0-25 F.P.S.( Pulse Strobe Macro) |
Over temperature protection | ||
| Total hours, DMX channel number, software versions are displayed and display inversion | |||
| Dimmer | |||
| 0-100% linearly adjustable |
HOUSING |
||
|
High temperature engineering-plastic |
|||
| Effect |
IP20 |
||
| Rainbow, Wash, Beam, Profile, Effect modes(kaleidoscope, swirl), multiple macros | |||
| Net Weight | |||
| Light Angle | 30kg | ||
|
Beam angle(1/2 peak) θ1/2： Linear Zoom 3.3°～ 60° |
|||
| Head Movement | |||
|
Pan 0-540 degrees, Tilt 0-210 degrees with auto-positioning |
|||
|
Bi-directional and continual rotation for the front lens panel |
|||
| Control | |||
|
International Standard DMX512 signal, 5 pin DMX512 interfaces |
|||
| Color System | |||
| Linear RGBW ,color mixing with unlimited colors, macros | |||
