| Electric parameters Input voltage: 100V~240VAC，50/60Hz Power consumption: 390W@ 220V Rated current: 1.8A @ 220V Powerfactor: PF>0.9 Lightsources Lightsources 260Wlasermodule Colortemperature 9000K Rated life 12000hrs Prism/frost： 3 prism wheels: (a 8-facet circular prism+ a 4-facet linear prism )+ (a 16-facet circular prism + a frost filter), Other prism options available. Focus DMX linearfocus Strobe/dimmer Double flag strobe，0.3-25 F.P.S. / linear dimmer Movements Pan (0°-540°)，Tilt( 0°-270°) with auto positioning correction function Beam angle Beamangle：0.8° |
Control Internationalstandard DMX 512 signal,5-pin XLRconnectors ShortMode 15 channels，standard Mode 17channels,extendedmode 18channels Selftest mode Other functions Pan andTiltspeeds adjustable Lamp hours and fixture hours displayed Modular construction easy for maintenance 17Wirelessreceiver Wirelesstransmitter ( Optional) ArtNet and sACN ( Optional) Housing and ingress protection Cast aluminumand high temperature andUVresistantABS with IP66 Weight Net weight：37.6Kg Ambient temperature -20 °C ~ 45 °C Note：If a fixture runs with the ambient temperature below 0 Celsius, it should be heated for some time(less than 20 minutes based on actual conditions) before turning on the lasermodule. |
| 【Version:20240424】 |
