Input Voltages | Control | ||
200-240V AC, 50/60Hz | International DMX512, 5 pins(optional 3 pins) interface | ||
RDM control protocol | |||
Power Consumption | Short mode 28 channels, standard mode 32 channels and extended mode 39 channels | ||
2500W/1800W@220V | Self-test mode | ||
Light Source | Other Functions | ||
OSRAM lok-it 2000/PS(CRI>90, 6000K, 750 hrs), (PR-2960) | Adjustable pan & tilt speed | ||
OSRAM lok-it 1400/PS(CRI 90, 6000K, 750 hrs), (PR-2920) | Lamp and total hours displayed | ||
LCD English display with contrast and brightness adjustable | |||
Strobe | Energy saving ballast | ||
Double shutter blades, 0.3-25 F.P.S | Built-in sensor diagnostic system | ||
Built-in chargeable battery and menu setting without power mains | |||
Dimmer | Input signal isolation | ||
0-100% linear adjustment | Modular structure for easy maintenance | ||
Ethernet interface | |||
Prism | DMX512 wireless receiver | ||
One 3-facet prism, bi-drectionally rotating at variable speed, indexable | DMX512 wireless transmitter(optional) | ||
Frost | Physical | ||
One frost filter, linear frost effect | Housing: composite plastic, IP20 | ||
Ambient working temperature: maximum 40°C | |||
| Effect | |||
One interchangeable animation(ripple or flame effect) | Weight | ||
Bi-directionally rotatable at variable speeds | Net weight: 45Kg | ||
Iris | Packaging | ||
5-100% linear adjustment with macros | Standard: carton 855x675x758(mm) | ||
Optional: flight case 685x626x940(mm) | |||
Focus | |||
DMX linear focus | Accessories | ||
G clamp, 2 pcs | |||
Zoom | 5 pins XLR connector, 1 set | ||
DMX linear zoom | Safety cord, 2 pcs | ||
Power cord, 1 pc | |||
Head Movement | Spare gobos, 4 pcs | ||
Pan 540°, tilt 270° with auto position correction | Optional: Ω clamp 2 pcs | ||
Light Angle | |||
6°~55° | |||
| CMY | |||
CMY linear mixing system with macros | |||
| Color Wheel | |||
1 Color wheel: 7 dichroic color filters plus open | |||
Half color effect, rainbow effect with bi-directional and variable speeds | |||
Stepping/linear color changing | |||
| Fixed Gobo | |||
| 1 Fixed Gobo Wheel: 7 replaceable gobos plus open | |||
Shaking at variable speed and bi-directional scrolling effect | |||
| Rotating Gobo | |||
| 2 Rotating Gobo Wheels: each with 6 replaceable gobos plus open, glass and metal gobos can be fixed | |||
| Bi-drectionally rotating, index, shaking at variable speed and bi-directional scrolling effect | |||
